| Technical items | 2LAN+1POTS+WiFi+CATV EPON HGU |
| PON interface | 1 GPON interface, SC single-mode/single-fiber, symmetric 2.5Gbps |
| Wavelength | Tx 1310nm, Rx 1490nm CATV 1550nm |
| Optical interface | SC/PC |
| LAN interface | 2*10/100Mbps or 1*10/100Mbps and 1*10/100/1000Mbps Auto adaptive Ethernet interfaces, Full/Half Duplex, RJ45 connectors |
| POTS interface | 1 FXS, RJ11 connectors |
| Indicators | 8 indicators |
| DC power supply | +12V /1A, external AC-DC power adaptor |
| Power consumption | ≤ 8W |
| Operating condition | Operating temp: -5 ~ +55℃ Operating humidity: 10~90% (non-condensing) |
| Storing condition | Storing temp: -30 ~ +60℃ Storing humidity:10~90%(non-condensing) |
| Dimension | 185mm*120mm*34mm(length*width*height) |
| Net weight | 0.29kg |
